This Borum Industrial Hydraulic Bead Breaker delivers 5,000kg of force in seconds and is designed to work on most truck and tractor rims up to 26". Ideal for use with all trucks, tractors, graders, harvester and skidder tyres, it suits all types of rims except 5-piece earthmover rims. It is expressly intended to be used as an aid in breaking the bead seal between a tyre and it's one, two or three piece wheel rim for the purpose of reseating a bead seal, replacement of tyre or wheel and replacing tyre valves, tyre tubes etc.  This Borum Industrial Hydraulic Bead Breaker can perform tyre work or tyre replacements without ever removing the wheel from the vehicle. This quality unit is excellent for field maintenance use on agricultural machines.

The bead breaker works directly on the bead of the tyre and will not damage the tyre if used correctly when used with the optional TradeQuip 2054T 10,000 psi air/hydraulic pump and the TradeQuip 2054H 10,000 psi hydraulic hose.

Features

• Economical solution for agricultural wheels and 1, 2 and 3piece truck tyre rims
• Hydraulically clamps on wheel
• Durable steel construction
• Clamps to wheel rim & breaks bead simply with up to 5,000kg of force
• Requires 10,000psi air/hydraulic pump (sold separately)
• Most popular tool for breaking beads on most agricultural tyres

Specifications

• Safe Working Capacity: 5,000kg
• Rated Pressure: 10,000psi
• Maximum Rim Diameter: 660mm (26")
• Maximum Rim Width: 125mm  (5")
• Ram Stroke: 90mm
• Pressure Connection: 3/8" - 18NPTF
• Hydraulic Oil Capacity: 250ml
• Dimensions: 429x140x324mm
• Weight: 16kg
• Carton: 375x375x155mm

Intended Use

Designed to be used as an aid in breaking the bead seal between a tyre and it's one, two or three piece wheel rim for the purpose of reseating a bead seal, replacement of tyre or wheel and replacing tyre valves, tyre tubes etc.
